Hongfa HF2150-1A-5DEF High Power Relay SPST 30A 5V Coil Voltage UL CQC

Name: Hongfa HF2150-1A-5DEF High Power Relay SPST 30A 5V Coil Voltage UL CQC
Brand: Hongfa
Price: 77.00 PHP
Availability: InStock

Hongfa HF2150-1A-5DEF High Power Relay SPST 30A 5V Coil Voltage UL CQC

0 reviews - Write a review

₱77.00

Stock: In Stock
Brand: Hongfa
Product Code: 130800024
Product ID: 130800024

Hongfa

Qty

Add to Cart

Buy Now

Add to Wish List Compare this Product

Tags: relay

Description
Reviews

Coil Data
Nominal Voltage: 5.0 VDC
Pickup Voltage: 3.75V max
Dropout Voltage: 0.5V min
Max Voltage: 6.5 VDC
Coil Resistance: 27R
Coil Power: 900mW Approx

Contact Data
Contact Arrangement: 1A SPST
Contact Rating: 30A @ 240VAC, 20A @ 30VDC
Maximum Switching Power: 11080VA (1200W)

Safety Approvals: UL,CUL,CQC
