3S Li-ion 40A BMS Board 80A Over Current

3S Li-ion 40A BMS Board 80A Over Current
3S Li-ion 40A BMS Board 80A Over Current
3S Li-ion 40A BMS Board 80A Over Current
3S Li-ion 40A BMS Board 80A Over Current
3S Li-ion 40A BMS Board 80A Over Current
3S Li-ion 40A BMS Board 80A Over Current
3S Li-ion 40A BMS Board 80A Over Current
3S Li-ion 40A BMS Board 80A Over Current
3S Li-ion 40A BMS Board 80A Over Current
3S Li-ion 40A BMS Board 80A Over Current
3S Li-ion 40A BMS Board 80A Over Current
3S Li-ion 40A BMS Board 80A Over Current
3S Li-ion 40A BMS Board 80A Over Current
0 reviews - Write a review
₱109.00
  • Stock: In Stock
  • Product Code: 211000038
  • Product ID: 211000038
Add to Cart
Buy Now
Add to Wish List Compare this Product
Tags: kit , kit power supply , power supply , charger , kit charger , battery charger

Nominal Voltage: 11.1V
Rds (on): 3mR
Continous Current: 40A
Over Current Protection: 80A

Typical Performance (per cell)
Overcharge Protection Voltage: 4.3V
Over-Charge Recovery Voltage: 4.15V
Over-Discharge Recovery Voltage: 3.2V
Over Discharge Protection: 2.5V

Reminder:
Always put a heavy capacitor (>100uF/25VDC) across the BMS output terminals if you are using the battery to power brush DC motors. This will prevent the motor back-emf from damaging your BMS.

Write a review

Please login or register to review

Prices and stock availability subject to change without prior notice. If you want this product but it indicates it is not in stock, chat us or simply add it to your cart anyway. Our staff will contact you to inform if we can/cannot provide the item in your order.
