NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V

NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
NAIS Miniature LATCHING Bistable SPST 12V 8A Power Relay DSP1a-L2-DC12V
0 reviews - Write a review
₱195.00
  • Stock: In Stock
  • Brand: NAIS
  • Product Code: 130800030
  • Product ID: 130800030
NAIS
Add to Cart
Buy Now
Add to Wish List Compare this Product
Tags: relay

Genuine NAIS/PANASONIC Relay
Made in Japan

Double coil Bistable/Latching Relay.

Latching relay requires only momentary energization of the coil to switch ON or OFF contacts. Two separate coils correspondingly turn ON or OFF the contact.

Coil Data:
Nominal Voltage: 12VDC
Pickup Voltage: 9.6VDC
Dropout Voltage: 1.2V
Coil Resistance: 480R
Coil Current: 25mA

Contact Data:
Contact Rating: 8A @250VAC
Contact Resistance: 30mR max.
Contact Material: AgSnO2
Electrical Endurance: >100,000 operations
Set Time: 10ms max.
Reset Time: 10ms max.
Safety Approvals: UL, CSA
